AGM Rattler TC50-640 Clip-On
Original price was: $4,725.00.$4,295.00Current price is: $4,295.00.
Out of stock
The AGM Rattler TC50-640 is a compact thermal imaging clip-on system that allows quick transformation of the day optics into thermal imaging device without any special tools or equipment. Rattler TC50-640 has high sensitivity 12μm thermal detector with 640×512 resolution and 1024×768 OLED monitor, which provides clear image under harsh environment conditions like darkness, fog, smoke, dust, rain, snow, wood, camouflage, etc.
The product is mainly applied to scenarios such as patrolling, hunting, etc. The Rattler TC50-640 can easily be attached in front of rifle scopes with magnification up to 8x for long range use.
Onboard Wi-Fi module for live video streaming and video/images recording via application are also available.
- Quick conversion of daytime optics into thermal imaging scope
- 12μm high sensitivity detector
- 640×512 thermal resolution
- 1024×768 resolution 0.39-inch OLED display
- 8x digital zoom
- Video recording and snapshot, built-in EMMC (16 GB)
- Supports distance measurement
- Adjustable color palettes
- Wi-Fi data transmission
- Waterproof, shockproof
- Up to 4.5 hours continuous working
- External power supply capability
- Limited 3-year warranty
SPECIFICATIONS
Palettes
Black Hot, White Hot, Red Hot, Fusion
Shock and vibration
750 g/ms
Exit Pupil Diameter
22 mm
Distance Measurement
Yes (Stadiometric Rangefinder)
Scene Mode
Jungle, Recognition
Hotspot
Yes
Observation Distance
2,500 m
Detector type
12 μm VOx Uncooled Focal Plane Arrays
Response Waveband
8 μm to 14 μm
FFC (Flat Field Correction)
Auto, Manual, External Correction
Highest Temperature Spot Tracking
Yes
Standby Mode
Yes
Refresh rate
Sensor 50 Hz / OLED 50 Hz
Resolution
640 x 512
Lens system
50 mm, F1.0
Optical magnification
1x
Power
5 VDC/2 A, USB Type-C interface Supports external power supply
Mounting
Optional Front Quick Release Adapters for different front lens diameter or Quick
Field of view (H × X)
8.8° x 7.0°
Monitor
1024×768, 0.39 inch, OLED
Storage
Built-in 16 GB EMMC
Record Video
On-board video recording
Capture Snapshot
Yes
Battery Type
Two CR123A (3V) Lithium or two RCR123 (up to 4.2V) Rechargeable Batteries
CVBS Output
Yes (via USB)
Battery Operating Time
Up to 4.5 hours continuous running (@25°C, WiFi off) Up to 4.0 hours continuous running (@25°C, WiFi on)
Battery Capacity Display
Yes
Operating Temperature Range
-20°C to 55°C (-4°F to 131°F)
Weight
0.49 kg (1.08 lb)
Overall Dimensions
153 mm × 78 mm × 66 mm (6.0 × 3.1 × 2.6 in)
Protection Level
IP67
