NocPix ACE S60R 1280 Thermal Scope with Integrated Laser Rangefinder

Groundbreaking 1280 Thermal Optic Built for Precision Long-Range Hunting

The NocPix ACE S60R delivers a new benchmark in thermal imaging performance. Featuring a true 1280×1280 resolution Gen-2 HD thermal sensor, integrated laser rangefinder, and advanced Vision+ and Reality+ systems, this optic provides exceptional clarity, accuracy, and range in the harshest environments.

Designed for professional hunters and precision shooters, the ACE S60R offers a powerful combination of long-range thermal detection, rugged durability, and advanced shooting features in a traditional tube-style design.

Key Features

True 1280×1280 HD Thermal Resolution
Equipped with a next-generation 12μm thermal sensor and ≤15mK NETD sensitivity, the ACE S60R delivers unmatched clarity and heat signature detail. With a 50Hz refresh rate, image fluidity remains consistent during fast-paced scanning or target tracking.

Vision+ Display System with Round AMOLED
The 1.03-inch, 2560×2560 round AMOLED display is engineered for high-resolution viewing with zero distortion. Ocular zoom (1×–3×) enables magnification without sacrificing image quality, offering enhanced precision at all distances.

60mm / F1.0 Objective Lens for Superior Brightness
The fast F1.0 aperture maximizes light transmission, producing images up to 20% brighter than comparable optics. The 60mm lens offers a wide field of view (14.7° × 11.7°) for scanning and situational awareness while maintaining long-range capability.

Detection Range Up to 3100 Meters
The ACE S60R is built for extreme distances, with a thermal detection range of up to 3100 meters. Whether you’re glassing across fields or scanning distant ridgelines, this scope provides the visibility you need.

Integrated 1200m Laser Rangefinder
A built-in laser rangefinder is seamlessly integrated into the body, offering precise ranging up to 1200 meters. Optical and laser alignment is true to axis for consistent targeting and range estimation.

Reality+ Image Processing Algorithm
The proprietary Reality+ system enhances image clarity by reducing environmental noise and sharpening thermal detail—delivering consistent visibility even in fog, foliage, or difficult lighting.

Dual-Battery Power System
Includes a built-in 4000mAh internal battery and a replaceable 18650 external cell. The dual-power setup offers extended runtime and on-the-go flexibility, with up to 6 hours of continuous use per charge.

Durability and Environmental Protection
Machined from high-strength aluminum alloy and IP67-rated for water and dust resistance, the ACE S60R is built to withstand recoil, impact, and weather extremes. Operational temperature rating from -40°C to 55°C ensures reliable use in all seasons.

Essential Hunting Features

• Ballistic Calculator: Built-in trajectory support for precise long-range shots

• Recoil-Activated Video (RAV): Automatically records shots without manual input

• Auto Screen Shutdown: Conserves power during inactivity

• Shutterless Design: Operates silently for stealth in the field

Technical Specifications

Thermal Sensor & Imaging

• Resolution: 1280×1280 (12μm)

• Frame Rate: 50Hz

• NETD: ≤15mK

• Detection Range: 3100m

• Field of View: 14.7° × 11.7° / 26×21 m @ 100m

• Magnification: 2×–24×

• Ocular Zoom: 1×–3×

Optics & Display

• Objective Lens: 60mm / F1.0

• Display: 1.03″ AMOLED, 2560×2560 resolution

• Exit Relief: 50mm

• Exit Pupil Diameter: 8mm

Laser Rangefinder

• Range: Up to 1200 meters

• Optical Axis Alignment: True center

Power & Battery

• Built-in Battery: 4000mAh rechargeable lithium

• External Battery: Replaceable 18650

• Operating Time: Up to 6 hours

• Power Options: Dual-battery or USB-C external

Media & Storage

• Internal Memory: 64GB

• Recording: Video & Image Capture

• Features: Recoil-Activated Recording (RAV), multiple color palettes, ballistic calculator

Construction & Environmental

• Housing: High-strength aluminum alloy

• Waterproof Rating: IP67

• Operating Temperature: -40°C to +55°C

• Dimensions: 390×90×71mm

• Weight: 1300g (with battery)

Why Choose the NocPix ACE S60R?

• The industry’s first 1280×1280 resolution thermal scope

• Integrated 1200-meter laser rangefinder with true optical alignment

• Ultra-bright AMOLED display with distortion-free ocular zoom

• Dual-battery power system for long-lasting field operation

• Reality+ and Vision+ enhancement systems for ultimate image clarity

• Rugged, recoil-resistant housing with full IP67 weatherproofing

For serious hunters, precision shooters, and professionals who demand top-tier performance, the NocPix ACE S60R delivers next-generation thermal imaging in a familiar and proven design.
